1. Insulation Resistance : 100 §Û
2. Contact Resistance : 30 m§Ù Max (Par contact)
3. Current Capacity : 2A
4. Dielectric Strength : > 1000V AC
5. Life Time : 10,000 Cycles
6. Operating Temperature : -40¡É to 10¡É
Product Withstanding Reflow Soldering
260¡É for 10(s) |
 |
|
|
| ¡¡ |
[ MATERIAL ] |
|
|
| |
| HOUSING(INSULATOR) |
PA 46 STANYL (UL94V-0) |
| COLOR |
BLACK |
| CONTACT TERMINAL |
BERYLLIUM COPPER |
| CONTACT PLATE |
GOLD 0.15§ PLATED OVER
NIKEL 2§ MIN SOLDER
AREA TIN PLATED |
|
| ¡¡ |
[ MECHANICAL
DATA ] |
|
|
| |
| LANDING CONTACTS |
> 200,000 OPERATIONS |
| FRICTION CONTACTS |
100,000 OPERATIONS |
| CONTACT TERMINAL |
BERYLLIUM COPPER |
| CONTACT PLATE |
GOLD 0.15§ PLATED OVER
NIKEL 2§ MIN SOLDER
AREA TIN PLATED |
|
| ¡¡ |
[ ELECTRICAL
DATA ] |
|
|
| |
| CARD CONTACTS |
| INSULATION RESISTANCE |
> 10 §Û |
| TEST VOLTAGE |
50 Hz |
| * BETWEEN CARD CONTACTS |
> 1000 V rms |
* BETWEEN CARD CONTACTS
¡¡AND DETECTION CIRCUIT |
> 1000 V rms |
| CURRENT |
| * MIN |
10 §Ë |
| * MAX |
1 A |
| CONTACT RESISTANCE |
< 100 §Û |
| TEST VOLTAGE 50 Hz |
500 V rms |
|
| ¡¡ |
[ SOLDERABILITY
ACCORDING TO IEC 68.2.20 ] |
|
|
| |
| MANUAL |
250 ¡É / 2 s |
| WAVE |
220 ¡É / 5 s |
|
|
|
